ITS-600 Limit Switch Box
ITS position monitoring switch is used for the valve and actuators which rotates 90degree quarter turn. The first function of ITS is to provide the visual indication of the current position of the valve and actuator. Dome indicator unit shows current position by color indication.
Secondly ITS provide electrical signal at the fully open or closed position by activating mechanical switches (SPDT, SPST), Proximity sensors and other magnetic sensors which independently makes function. Switches vary in a wide range and construction to meet customer’s requirement.
|Model||ITS-600 Series||Position indication||Close- Red; Open-Green|
|Shell material||Die-casting aluminum||Cam type||Round cam, red and yellow|
|Shell coating||Polyester paint, black||Micro Switch Contacts||Mechanical micro switch|
|Micro Switch type||Mechanical switch, 2-SPDT||Micro Switch Brand||Chinese brand/ Omron|
|Terminal block||8 position, Copper core||Rated Current||DC250V, 0.3mA|
|Voltage Range||Max 250VAC/DC||Ambient temperature||-20℃- 60℃|
|Protection Class||IP67||Bracket Type||Movable mounting bracket|
|Interface thread||2XG1/2” (M20*1.5)||Bracket Material||Carbon steel paint|
